1, Pattern descriptions:
Design character:
Widened flat structure and deep pattern
3-layer construction
Super deep pattern with attrition sign
Pattern benefits:
² High loading,
² low rolling resistance,
² lower energy consumption,
² higher wear resistance,
² no exp-loading,
² lower cost of maintenance,
2, Products Technical Details:
No | Size | Rim size | Overall Dia | Section Width | Max Load/Kgs | Tire With hole | Pattern |
Inch | mm | mm | 10km/h | YES/NO |
1 | 6.50-10 | 5.00 | 570 | 163 | 2500 | YES/NO | OTR-1 |
2 | 16.00-25 | 11.25/2.0 | 1446 | 390 | 10130 | YES/NO | OTR-1 |
3 | 17.5-25 | 14.00-25 | 1360 | 440 | 8250 | YES/NO | OTR-1 |
4 | 20.5-25 | 17.25 | 1490 | 520 | 11500 | YES/NO | OTR-1 |
5 | 23.5-25 | 19.50 | 1612 | 588 | 13600 | YES/NO | OTR-1 |
6 | 28x9-15 | 7.00 | 700 | 226 | 400 | YES/NO | OTR-1 |
7 | 17.5-25 | 11.25 | 1368 | 458 | 17720/14180 | YES/NO | OTR-2 |
8 | 20.5-25 | 17.00 | 1455 | 500 | 24430/18820 | YES/NO | OTR-2 |
9 | 23.5-25 | 19.50 | 1620 | 580 | 30830/24660 | YES/NO | OTR-2 |
10 | 26.5-25 | 22.00 | 1715 | 642 | 39300/31400 | YES/NO | OTR-2 |
11 | 29.5-25 | 25.00 | 1840 | 730 | 48100/37055 | YES/NO | OTR-2 |
12 | 16.00-25 | 11.25/2.0 | 1446 | 390 | 16860/13490 | YES/NO | OTR-2 |
13 | 18.00-25 | 13.00 | 1607 | 480 | 21200/16960 | YES/NO | OTR-2 |
14 | 16.00-25 | 11.25 | 1446 | 390 | 16860/13490 | YES/NO | OTR-3 |
15 | 18.00-25 | 13.00 | 1620 | 500 | 21200/16960 | YES/NO | OTR-3 |
16 | 17.5-25 | 14.00-25 | 1370 | 458 | 17720/14180 | YES/NO | OTR-4 |
17 | 23.5-25 | 19.50-25 | 1620 | 580 | 30830/24660 | YES/NO | OTR-4 |
3, Applications:
This tire is suitable for heavy dump trucks,scrapers and loaders under the condition of a variety of assignments.Beside,such kind of tire is widely used on the special vehicle like front Crane, Gantry Crane, Loader etc.Widely used as durable tires in various mines and construction sites.
4, OEM remarks:
We can produce tires with rim using cured-on production technology; But we need your support for bulk or OEM production.
We need to know wheel spoke details as below:
1) Model
2) Screw hole number(quantity) and diameter of the hole
3) Offset
4) P.C.D
5) Centre hole Diameter
6) If you have drawing will better (photos also okay)
7) Your using conditions (temperature, road, loading, lasting use time...etc)
5, Our services:
² R&D support
² After sales warranty & guarantee
² Sample for testing
² Testing report
² Special certificates operation, example：SABER, SGS, INTERTECK...
² Nice packing
² Customer clearance doc
² Shipments arrangement
6, Business Terms:
① Delivery time: within 30 days generally.If urgent order, we can shipping within 7 days without delay.
② Customized brand: acceptable for regular order
③ Payments term : T/T, Western Union, Cash, Paypal;
④ Mini order qty: no quantity limitation. But if less than one container, customer need to bear domestic logistic(transportation) cost from factory warehouse to port.
